Dynamixel PRO PLUS PM54-060-S250-R Servo
Dynamixel PRO PLUS PM54-060-S250-R Servo

Dynamixel-P PM54-060-S250-R Servo

Dynamixel PRO PLUS PM54-060-S250-R Servo
Robotis | A-000000-04211
€2,255.12
Tax included

Including €0.10 for ecotax

The Dynamixel M54P-060-S250-R servo motor will satisfy the most ambitious roboticists, looking for an ultra-precise, fast, fully configurable and durable servo. It’s a powerful machine for your most sophisticated projects.

Quantity
Delivery within 4 weeks
Generate a quote

Size Chart
x
Size Chart
Payment methods (see T&C)
Debit card
PayPal
Payment by invoice
Wire transfer

Dynamixel M54P-060-S250-R servo motor: in the running for breaking some precision records

The latest addition to the Robotis range, the Dynamixel M54P-060-S250-R servo motor belongs to the Dynamixel-P series of next-generation servos featuring two absolute contactless and incremental encoders. So your servo benefits from a resolution twice as high as its equivalent model in the -P series. Its response time is also significantly better.

Like all the Dynamixel-P models, this servo with an RS485 interface is equipped with a JST connector and benefits from a high-quality design: its precious metal delivers satisfactory heat dissipation, noise reduction and service life.

Create high performance projects with the M54P-060-S250-R servo

In addition to this kind of performance, you’ll benefit from features already familiar to many Dynamixel users: multiple control modes (including PWM), almost endless programming possibilities, and so on. The result is one of the most efficient servos on the market for consumer robotics, which adapts just as well to amateur engineering as to research or industrial needs.

Servomoteur Dynamixel-P vue 3D

Plus, the Dynamixel M54P-060-S250-R servo motor offers various mounting options, being compatible with a great many assembly parts also available on our site. Humanoid robot, industrial manipulator, robotised video system, autonomous mobile vehicle... These are just a few examples of the projects that you can build using this smart, versatile, lightweight and energy-efficient servo.

Technical specifications of the Dynamixel M54P-060-S250-R servo by Robotis

  • Cortex-M4 controller (168 Mhz, 32 bits)
  • Voltage rating: 24V
  • No-load speed: 33.1 RPM
  • No-load current: 1.25A
  • Torque: 10.1 Nm
  • Speed: 28.3 RPM
  • Current rating: 3A
  • Resolution:
    • 0.0007° per revolution
    • 502,834 pulses per revolution
    • Angle: 360°
  • Position sensor: absolute contactless encoder, incremental encoder
  • Operating temperature: -5 to 55°C
  • BLDC Maxon motor
  • Baud rate: 9,600 to 10,500,000 bds
  • PID control algorithm
  • Gear type: cycloid
  • Material (gear and case): precious metal
  • Dimensions: 54 x 126 x 54 mm
  • Weight: 855 g
  • Reduction ratio: 251.4:1
  • Control signal: digital packets
  • Protocol: half-duplex asynchronous serial communication (8 bits, 1 stop, no parity)
  • Connection: RS-485 multidrop bus
  • Addresses: 253 IDs (0~252), ID 1 selected by default
  • Protocol version: 2
  • Feedback: position, velocity, current, temperature, input voltage, external port, etc.
  • Control modes: torque, velocity, position, extended position, PWM, etc.
  • Output: 60W
  • Standby current: 40 mA

Resources for the Dynamixel-P M54P-060-S250-R servo

We’ve listed below all the resources you’ll need to get started with your Dynamixel M54P-060-S250-R servo motor:

    My Dynamixel servomotor is not detected, what can I do about it ?

    Check that your Dynamixel servomotor is correctly configured. Do not hesitate to re-flash it with the ROBOTIS Software Roboplus. After re-flash remember to re-configure it. If the issue is not solved, contact us for an advanced support.

    My motor works but it seems like there is an offset. Why ?

    The motor is probably not well mounted. Check that you correctly mounted the horns by respecting the mark.

    My Dynamixel servomotor seems blocked. I can't turn it even when it is not alimented.

    There is probably a mechanical issue with the Dynamixel servomotor. You can directly contact us to get more advance support.

    My Dynamixel servomotor is not working properly.

    Check your power supply and the system cabling (try with a different servomotor). You can also reset the servo. If nothing works, the best solution is to go through the Dynamixel servomotor checklist!

    What is the difference between Protocol 1.0 and Protocol 2.0?

    The 1.0 protocol is dedicated to the Dynamixel AX and MX series. Protocol 2.0 is for the X and Dynamixel Pro series. Protocol 2.0 control tables include PID controls which allow for more precise adjustment of the servo motor movements. Protocol 2.0 can be updated on MX series servo motors. You can refer to the protocol 1.0 and protocol 2.0 pages for more informations.
