Brushed Motor Controller Roboteq 1 x 40A 60V - SDC 2160 S

Roboteq SDC 2160 S Controller: the most powerful in its class

Roboteq offers various types of motor controllers: single-channel or multi-channel, for brushed or brushless motors... And the SDC 2160 is the most powerful in the range of brushless motor controllers. This single-channel controller converts your control signal into an output voltage up to 60V and a power output up to 40A.

Like all Roboteq motor controllers, it accepts a wide variety of control signals thanks to its reconfigurable analogue and digital I/Os. And don’t forget that you can network up to 127 controllers thanks to CAN bus communication.

Suitable for many applications with Roborun+

The Roboteq controller’s operation can be extensively reconfigured and automated using MicroBasic language scripts. The Roborun+ PC utility is available for free download in our resources below, but you can purchase a Pro licence for more ambitious programming projects. Plus, the new Roboteq OS can be used to reprogram your controller in full so that it supports new applications.

Technical specifications of the SDC 2160 S single-channel controller

• Compatible motor type: brushed DC
• Voltage rating: 60V max.
• Number of channels: 1
• Direction: forward/reverse
• Power per channel: 40A max.
• Continuous power per channel: 20A
• ON resistance: 20 mOhms
• Power connections: screw terminal
• Communication: analogue, RS232, USB, CAN bus
• Programming: MicroBasic scripts
• Control loop: 1 ms
• Regenerative braking
• Analogue inputs: 4 max.
• Digital inputs: 6 max.
• Digital outputs: 2
• Pulse inputs: 5 max.
• Encoder: yes
• Cooling: conduction plate
• Safe Torque Off (STO): no

• Dimensions: 70 x 70 x 20 mm
• Weight: 100 g

Resources for the SDC 2160 S controller

Learn more about your Roboteq SDC 2160 S controller in the resources below!

• Datasheet Brushless Motor Controller SDC 2160S - Roboteq
• Datasheet errata
• Roboteq controller user manual v2.0
• Roborun+ user guide
• Roborun+ PC utility
• MicroBasic scripting manual
• CAN networking manual
• ModBus manual
• Downloads (Firware)
