ZED X One Depth Camera
ZED X One Depth Camera
ZED X One Depth Camera
ZED X One Depth Camera
ZED X One Depth Camera
ZED X One Depth Camera
ZED X One Depth Camera
New
ZED X One Depth Camera

ZED X One Depth Camera

ZED X One Depth Camera
Stereolabs | A-000000-07671
€624.00
20 perc. French VAT inc.

The ZED X One is a high-performance depth camera designed for long-range 3D perception, teleoperation, and smart analytics, with multi-camera synchronization and integrated IMU sensors.

Image Sensor
-- Please select an item --
  • Global Shutter
  • 4K Rolling Shutter
Field of view
-- Please select an item --
  • Narrow
  • No lens
  • Wide
Quantity
Resupply in progress
This product is currently being replenished. Restocking occurs on a monthly basis.
Contact us

Create a cart and turn it into a quote instantly!
Payment methods (see T&C)
Debit card
PayPal
Payment by invoice
Wire transfer

ZED X One Camera: A Professional Stereo Vision Solution for Robotics and Research

The ZED X One is optimized for demanding robotic applications. Equipped with high-resolution sensors (2.3 MP or 8 MP depending on the version), a high-frequency integrated IMU, and a secure GMSL2 connection, it delivers stable and synchronized video streams with high temporal accuracy. With its compact size (31 x 31 mm) and lightweight design (50 g), it can be easily integrated into mobile robots, drones, or embedded research platforms.

Three versions are available to match your needs:

  • ZED X One GS Narrow: precise and centered vision
  • ZED X One GS Wide: wide field of view with global shutter
  • ZED X One 4K HDR Wide: ultra-detailed 4K imaging with HDR technology

The camera is compatible with the ZED SDK, making it easy to integrate into perception, 3D mapping, or autonomous navigation systems. Thanks to GMSL2 technology, it benefits from power and data transmission via a single coaxial cable, which improves reliability and robustness in field deployments.

Possible Applications of the ZED X One

  • Stereo 3D vision in complex environments
  • Teleoperation and remote control systems
  • Long-range perception for autonomous vehicles
  • Obstacle detection, SLAM, and mapping
  • Industrial monitoring and smart analytics
  • Synchronized multi-camera capture for motion analysis
  • Research in computer vision, AI, and mobile robotics

Included in the Box

  • 1x ZED X One
  • 1x 1.5m GMSL Female-to-Female Cable
  • 1x Adapter Plate

ZED X One Camera – Technical Specifications

CameraZED X One GS NARROWZED X One GS WIDEZED X One 4K HDR WIDE
Weight50g55g59g
Dimensions31mm x 31mm x 52mm31mm x 31mm x 52.7mm31mm x 31mm x 58.1mm
Operating Temperature-20°C to +55°C-20°C to +55°C-20°C to +55°C
Video Output1920x1200 @15/30/60fps
1920x1080 @15/30/60fps (cropping mode)
960x600 @15/30/60/120fps (binning mode)		1920x1200 @15/30/60fps
1920x1080 @15/30/60fps (cropping mode)
960x600 @15/30/60/120fps (binning mode)		3840x2160 @15/30/60fps
1920x1080 @15/30/60fps (cropping mode)
960x600 @15/30/60/120fps (binning mode)
Motion Sensors200Hz / 400Hz 16-bit Accelerometer (up to 12g)200Hz / 400Hz 16-bit Accelerometer (up to 12g)200Hz / 400Hz 16-bit Accelerometer (up to 12g)
Lens TypeNarrow (4mm)Wide (2.2mm)Wide (3.1mm)
Field of View (FOV)91°(D) 80°(H) 52°(V)120.8°(D) 110°(H) 79.6°(V)118.8°(D) 109.9°(H) 71.8°(V)
Sensor Size1/2.6”1/2.6”1/1.8”
Resolution2.3M pixels2.3M pixels8.2M pixels
Sensor Format16/1016/1016/9
ConnectorSerial coax GMSL2 - FAKRA Z typeSerial coax GMSL2 - FAKRA Z typeSerial coax GMSL2 - FAKRA Z type
Mounting Options4x M4 (bottom) + 1/4"-20UNC adapter plate4x M4 (bottom) + 1/4"-20UNC adapter plate4x M4 (bottom) + 1/4"-20UNC adapter plate
PowerGMSL2 (PoC)GMSL2 (PoC)GMSL2 (PoC)
Capture Card CompatibilityNVIDIA Jetson Orin and Xavier PlatformsNVIDIA Jetson Orin and Xavier PlatformsNVIDIA Jetson Orin and Xavier Platforms
