DYNAMIXEL Shield for Arduino MKR Series
DYNAMIXEL Shield for Arduino MKR Series
DYNAMIXEL Shield for Arduino MKR Series

DYNAMIXEL Shield for Arduino MKR Series

DYNAMIXEL Shield for Arduino MKR Series
Robotis | A-000000-06057
31.82 €
20 perc. French VAT inc.

The DYNAMIXEL MKR shield is an extension board that plugs into the popular Arduino MKR.

Quantity
In backorder
This product is on backorder. You can place an order on our website or send us a purchase order in PDF format
Contact us to know the delivery times
Ask for a quote

Size Chart
x
Size Chart
Payment methods (see T&C)
Debit card
PayPal
Payment by invoice
Wire transfer

Introduction to the DYNAMIXEL Shield for Arduino MKR Series

The DYNAMIXEL MKR shield is the ideal solution for connecting your DYNAMIXEL (TTL half-duplex) to the MKR series of Arduino boards.

The board is fully compatible with the Arduino IDE, promising easy integration and configuration.

You get:

  • 1 DYNAMIXEL Shield for Arduino MKR Series
  • 2 JST (S3B-EH)
  • 2 Molex (5268-03A)
  • 1 DC Jack Harness
  • 1 battery connector (SMW250-02)
  • 1 XL-320 convertible cable

Technical specifications

  • Voltage: 3.5~24 V
  • Operating temperature: -10~+80 °C
  • Connectors: JST (S3B-EH), Molex (5268-02A), battery connector3 (SMW250-02), terminal block (DG350-3.5-02P-14)
  • Physical connection: TTL multidrop bus (3.3 V logic, 5 V compatible)
  • Cables: DC Jack Harness (Type A, O.D.: 5.5 [mm], I.D.: 2.5 [mm]), convertible cable for XL-320
  • Dimensions: 65 x 25 mm
  • Weight: 11 g

Resources for the DYNAMIXEL Shield for Arduino MKR Series
