Luxonis OAK-D Pro W Camera

Luxonis OAK-D Pro W Camera

Luxonis OAK-D Pro W Camera
Luxonis | A-000000-06312
560.35 €
20 perc. French VAT inc.

OAK-D Pro W offers a wide field of view and is ideal for a multitude of possible projects.

Quantity
Delivery within 2 weeks

Payment methods (see T&C)
Debit card
PayPal
Payment by invoice
Wire transfer

An ultra-wide field of view

OAK-D Pro W is a Series 2 OAK camera offering the following features:

  • An IR illumination LED for perceiving low-light and no-light environments
  • An IR laser dot projector (active stereo) for improved depth perception, especially for low-visual-interest surfaces (little or no surface texture)
  • A wide field of view, making it ideal for many types of project
  • 4 TOPS of processing power and the ability to run any AI model


The only differences between this model and OAK-D S2 are the IR laser dot projector, the IR illumination LED and the wide field of view.

Luxonis camera field of view

Left: normal field of view / Right: wide field of view


USB and PoE: the differences

The OAK-D Pro W comes in 2 versions:

  • A USB version with a USB-C connector for power and communication
  • A PoE version equipped with an industrial M12 PoE connector (instead of a single RJ45) for power and communication, plus an M8 connector for IO connectivity

Comes in 2 versions:

The standard versions of both models (USB and PoE) come with the IMX378 RGB camera, although there is also a more sophisticated version with a OV9782 RGB camera.

Sensor IMX378 OV9782
DFOV / HFOV / VFOV 120° / 95° / 70° 150°/127°/79.5°
Resolution 12MP (4032x3040) 1MP (1280x800)
Focus FF: 60cm - ∞ FF: 19.6 cm - ∞
Max Framerate 60 FPS 60 FPS

This product is a Class 1 laser product under international standard EN/IEC 60825-1, edition 3 (2014).

Technical specifications of the OAK-D Pro W RGB camera

OAK-D Pro W

  • USB-C connector for both power and communication, supporting USB2 and USB3 protocols (5Gbps / 10Gbps)
  • IR illumination LED: allows perceiving low-light and no-light environments
  • IR laser dot projector (active stereo): improves depth perception, especially for low-visual-interest surfaces (little or no surface texture)
  • 4 TOPS of processing power (1.4 TOPS for AI)
  • Run any AI model, even custom architectured/built ones
  • Encoding: H.264, H.265, MJPEG - 4K/30FPS, 1080P/60FPS
  • Computer vision: warp/dewarp, resize, crop, edge detection, feature tracking
  • Object tracking: 2D and 3D tracking
  • Dimension: 97x29.5x22.9 mm
  • Weight: 91g

Package includes:

  • OAK-D Pro W camera
  • Y-Adapter
  • Cable USB-CA-1m

OAK-D Pro W PoE

  • M12 X-Coded Ethernet, 802.3af PoE, 1 Gbps Ethernet
  • M8 connector with quite a bit of IO flexibility, including USB2 host
  • IP65 Sealed casing/protection
  • Dimensions: 111x40x31.3mm
  • Weight:184 g

Package includes:

  • OAK-D Pro W PoE camera
  • M12 plug to RJ45 cable, 2m
  • M8 plug male to male cable, 2m
  • Cleaning cloth

PoE injectors are not included in the package.
